Introduction

When people talk about breakthroughs in artificial intelligence, they usually think about chatbots, self-driving cars, or smart assistants. But behind all of these systems is something far less visible and far more powerful: the AI chip. These chips—built by companies like NVIDIA, Google, TSMC, and SK hynix—are the engines that make today's AI possible. Understanding them doesn't require being an engineer. It only requires knowing why these chips exist, how they're built, and why they have suddenly become some of the most valuable pieces of technology on earth.

Why We Need AI Chips in the First Place

AI models learn by doing millions or billions of tiny math operations simultaneously. A normal CPU, like the one in a typical laptop, is extremely good at doing a few operations very quickly, but it is not designed to handle millions of parallel tasks all at once. Deep learning, however, thrives on this type of massive parallelism. Because of this, the computing world needed a new kind of processor—one built for thousands of small calculations happening at the same time.

NVIDIA: The Unexpected King of the AI Era

NVIDIA originally designed GPUs for video games, but the same features that made games look realistic turned out to be ideal for the math that powers modern AI. Over time, NVIDIA transformed from a gaming company into the world leader in AI processors by excelling in both hardware design and software infrastructure.

NVIDIA's modern AI GPUs, such as the H100 or the newer B100, are huge slabs of silicon densely packed with specialized math engines called tensor cores. These chips can perform trillions of operations per second while consuming enormous amounts of electricity—sometimes up to 700 watts of power when fully loaded. They are essential for both training AI models from scratch and for running those models once they've been trained. Training systems like GPT requires thousands of these chips working together.

But hardware alone didn't make NVIDIA dominant. The company created CUDA, a software platform that lets developers control GPUs easily and efficiently. CUDA functions as both a universal language for AI developers and a massive library of tools that simplify GPU programming. It quickly became the foundation on which nearly all AI research was built. Hardware can be copied, but a software ecosystem cannot, and this is the "secret weapon" that keeps NVIDIA far ahead of its competitors.

Google's TPU: A Different Path to the Same Goal

While NVIDIA built general-purpose GPUs that became the AI industry standard, Google took a different approach by inventing the Tensor Processing Unit (TPU), a processor built specifically for deep learning. TPUs focus on performing the types of matrix operations that dominate neural network workloads, and they do it with exceptional power efficiency.

A TPU combines large matrix multiplication units, high-bandwidth memory, and high-speed internal interconnects that allow multiple TPUs to communicate rapidly. These chips were originally created to make Google products—such as Search, YouTube, Translate, and Gmail—faster and more cost-effective. Today, they also power Google's own AI models, including Gemini. TPUs are used for both training and inference, just like NVIDIA GPUs, but are primarily available inside Google's data centers rather than sold directly to customers.

TSMC: The Invisible Giant That Manufactures the Future

Although companies like NVIDIA and Google design their chips, they do not physically manufacture them. That job falls to TSMC, the Taiwanese semiconductor manufacturer that produces the world's most advanced chips. TSMC provides the cutting-edge manufacturing processes—using mind-bendingly small transistors at sizes like 3nm or 5nm—that make these AI chips so powerful.

In addition to fabrication, TSMC provides advanced packaging technologies such as CoWoS, which allows high-bandwidth memory to be attached directly to the processor. This tight integration is essential for AI chips, which need an enormous stream of data to stay productive. TSMC is the silent backbone of the AI revolution; without their manufacturing precision, neither NVIDIA GPUs nor Google TPUs would exist in usable form.

SK hynix: The Memory Powerhouse Feeding the AI Beast

Modern AI chips require an incredible amount of memory bandwidth. To supply that, companies rely on HBM (High Bandwidth Memory), a special kind of memory designed to move huge amounts of data every second. SK hynix is currently the world leader in producing HBM and has become one of the most important players in the AI supply chain.

HBM is constructed as a stack of memory layers built vertically, almost like a microscopic skyscraper. This structure allows extremely fast data movement, and the memory stack is placed right next to the AI processor using advanced packaging from TSMC. For example, a single NVIDIA H100 GPU uses 80 GB of this high-speed memory, and the memory alone can cost hundreds or even thousands of dollars per chip depending on the generation. HBM shortages are one of the main reasons AI GPUs have been difficult for companies to obtain.

How Expensive Are These Chips?

AI hardware is extraordinarily expensive. An NVIDIA H100 can cost anywhere from around $25,000 to $40,000 depending on configuration and market demand. Newer chips such as the B100 or B200 are expected to cost even more, often ranging from $35,000 to over $60,000. Google's TPUs aren't sold individually, so their price is hidden inside Google Cloud billing; users access them by paying hourly rates rather than buying them outright. A full-scale AI training cluster can easily cost hundreds of millions of dollars when hardware, memory, networking, and power systems are included.

How Do You Connect 10,000 Chips Together?

A single GPU is powerful, but AI breakthroughs rely on connecting thousands of them. To link 10,000 chips into a single training system, companies use a combination of fiber-optic cables, specialized switches, and ultra-fast interconnect technologies such as NVIDIA's NVLink and InfiniBand networking. These connections allow chips to share data rapidly enough that they behave almost like one massive processor working on a single problem. Training systems like GPT-4, Gemini, and other frontier models all rely on supercomputers built from thousands of interconnected AI chips.

How Much Electricity Do They Use?

AI chips consume enormous amounts of electricity. A single NVIDIA H100 running at full capacity can draw up to 700 watts. When a cluster uses ten thousand of these processors for weeks or months of training, the total power consumption can exceed ten megawatts—the same electricity required to power a small town. Energy costs have become one of the biggest factors in the economics of AI.

Training vs. Answering Questions: Do They Use the Same Chips?

Training an AI model and answering questions with it—known as inference—both use similar types of chips, but the workloads are different. Training requires thousands of chips operating continuously for long periods. It demands the most memory, the most bandwidth, and the most communication between processors. Inference, by contrast, uses far fewer chips and can often be done with smaller or older hardware. Still, because GPUs and TPUs are so efficient for AI calculations, they remain the preferred hardware for both tasks.

Training is like building the brain; inference is like using the brain.

Why All This Matters

The AI revolution is not solely about algorithms or breakthroughs in software. It is built on top of physical machines—chips, memory stacks, high-speed wires, and factories—that make intelligence possible at scale. Companies like NVIDIA, Google, TSMC, and SK hynix are shaping the future by designing and manufacturing the hardware foundations on which modern AI stands.

In a way, AI isn't magic. It's math running on silicon and silicon running on electricity, all operating at a global scale never seen before. The more you understand the chip ecosystem behind AI, the clearer the future of technology becomes.
